Jacek M. Zurada is a Polish-American computer scientist who is a Professor of the Electrical and Computer Engineering Department at the University of Louisville, Kentucky. His M.S. and Ph.D. degrees are from Politechnika Gdaṅska (Gdansk University of Technology, Poland). He has held visiting appointments at the Swiss Federal Institute of Technology, Zurich, Princeton, Northeastern, and Auburn, and at overseas universities in Australia, Chile, China, France, Germany, Hong Kong, Italy, Japan, Poland, Singapore, Spain, and South Africa. He is a life fellow of IEEE and a fellow of the International Neural Networks Society and Doctor Honoris Causa of Czestochowa Institute of Technology, Poland. == Research == Zurada's research covers neural networks, deep learning, data mining with emphasis on data and feature understanding, rule extraction from semantic and visual information, machine learning, decomposition methods for salient feature extraction, and lambda learning rule for neural networks. == Professional and editorial service == Zurada was the editor-in-chief of IEEE Transactions on Neural Networks (1998–2003), an associate editor of IEEE Transactions on Circuits and Systems, Pt. I and Pt. II, Action Editor in Neural Networks (Elsevier) and on the editorial board of the Proceedings of the IEEE. He is an associate editor of Neurocomputing, Schedae Informaticae, the International Journal of Applied Mathematics and Computer Science, and Editor of the Springer Natural Computing, Advances in Intelligent Systems and Computing and Studies in Computational Intelligence Book series or volumes. == Awards and honours == In 2003 he was given the title of Professor by the President of Poland. Since 2005 he has been an elected Foreign Member of the Polish Academy of Sciences. He also received five honorary professorships from foreign universities, including Sichuan University in Chengdu, China, and Obuda University in Budapest, Hungary.
YaDICs
YaDICs is a program written to perform digital image correlation on 2D and 3D tomographic images. The program was designed to be both modular, by its plugin strategy and efficient, by it multithreading strategy. It incorporates different transformations (Global, Elastic, Local), optimizing strategy (Gauss-Newton, Steepest descent), Global and/or local shape functions (Rigid-body motions, homogeneous dilatations, flexural and Brazilian test models)... == Theoretical background == === Context === In solid mechanics, digital image correlation is a tool that allows to identify the displacement field to register a reference image (called herein fixed image) to images during an experiment (mobile image). For example, it is possible to observe the face of a specimen with a painted speckle on it in order to determine its displacement fields during a tensile test. Before the appearance of such methods, researchers usually used strain gauges to measure the mechanical state of the material but strain gauges only measure the strain on a point and don't allow to understand material with an heterogeneous behavior. One can obtain a full in plane strain tensor by derivation of the displacement fields. Many methods are based upon the optical flow. In fluid mechanics a similar method is used, called Particle Image Velocimetry (PIV); the algorithms are similar to those of DIC but it is impossible to ensure that the optical flow is conserved so a vast majority of the software used the normalized cross correlation metric. In mechanics the displacement or velocity fields are the only concern, registering images is just a side effect. There is another process called image registration using the same algorithms (on monomodal images) but where the goal is to register images and thereby identifying the displacement field is just a side effect. YaDICs uses the general principle of image registration with a particular attention to the displacement fields basis. === Image registration principle === YaDICs can be explained using the classical image registration framework: === Image registration general scheme === The common idea of image registration and digital image correlation is to find the transformation between a fixed image and a moving one for a given metric using an optimization scheme. While there are many methods to achieve such a goal, Yadics focuses on registering images with the same modality. The idea behind the creation of this software is to be able to process data that comes from a μ-tomograph; i.e.: data cube over 10003 voxels. With such a size it is not possible to use naive approach usually used in a two-dimensional context. In order to get sufficient performances OpenMP parallelism is used and data are not globally stored in memory. As an extensive description of the different algorithms is given in. === Sampling === Contrary to image registration, Digital Image Correlation targets the transformation, one wants to extracted the most accurate transformation from the two images and not just match the images. Yadics uses the whole image as a sampling grid: it is thus a total sampling. === Interpolator === It is possible to choose between bilinear interpolation and bicubic interpolation for the grey level evaluation at non integer coordinates. The bi-cubic interpolation is the recommended one. === Metrics === ==== Sum of squared differences (SSD) ==== The SSD is also known as mean squared error. The equation below defines the SSD metric: S S D ( μ , I F , I M ) = 1 | Ω F | ∑ x i ∈ Ω F ( I F ( x i ) − I M ( T μ ( x i ) ) ) 2 , {\displaystyle SSD(\mu ,{\mathcal {I_{F}}},{\mathcal {I_{M}}})={\dfrac {1}{\left|\Omega _{F}\right|}}\sum _{x_{i}\in \Omega _{F}}\left({\mathcal {I_{F}}}(x_{i})-{\mathcal {I_{M}}}({T}_{\mu }(x_{i}))\right)^{2},} where I F {\displaystyle {\mathcal {I_{F}}}} is the fixed image, I M {\displaystyle {\mathcal {I_{M}}}} the moving one, Ω F {\displaystyle \Omega _{F}} the integration area | Ω F | {\displaystyle \left|\Omega _{F}\right|} the number of pi(vo)xels (cardinal) and T μ {\displaystyle {T}_{\mu }} the transformation parametrized by μ The transformation can be written as: T μ ( x ) = x + { Φ ( x ) } t { μ } . {\displaystyle T_{\mu }(x)=x+\left\{\Phi (x)\right\}^{t}\left\{\mu \right\}.} This metric is the main one used in the YaDICs as it works well with same modality images. One has to find the minimum of this metric ==== Normalized cross-correlation ==== The normalized cross-correlation (NCC) is used when one cannot assure the optical flow conservation; it happens in case of change of lighting or if particles disappear from the scene can occur in particle images velocimetry (PIV). The NCC is defined by: N C C ( μ , I F , I M ) = ∑ x i ∈ Ω F ( I F ( x i ) − I F ¯ ) ( I M ( T μ ( x i ) ) − I M ¯ ) ∑ x i ∈ Ω F ( I F ( x i ) − I F ¯ ) 2 ∑ x i ∈ Ω F ( I M ( T μ ( x i ) ) − I M ¯ ) 2 , {\displaystyle NCC(\mu ,{\mathcal {I_{F}}},{\mathcal {I_{M}}})={\dfrac {\sum _{x_{i}\in \Omega _{F}}\left({\mathcal {I_{F}}}(x_{i})-{\overline {\mathcal {I_{F}}}}\right)\left({\mathcal {I_{M}}}({T}_{\mu }(x_{i}))-{\overline {\mathcal {I_{M}}}}\right)}{\sqrt {\sum _{x_{i}\in \Omega _{F}}\left({\mathcal {I_{F}}}(x_{i})-{\overline {\mathcal {I_{F}}}}\right)^{2}\sum _{x_{i}\in \Omega _{F}}\left({\mathcal {I_{M}}}({T}_{\mu }(x_{i}))-{\overline {\mathcal {I_{M}}}}\right)^{2}}}},} where I F ¯ {\displaystyle {\overline {\mathcal {I_{F}}}}} and I M ¯ {\displaystyle {\overline {\mathcal {I_{M}}}}} are the mean values of the fixed and mobile images. This metric is only used to find local translation in Yadics. This metric with translation transform can be solved using cross-correlation methods, which are non iterative and can be accelerated using Fast Fourier Transform . === Classification of transformations === There are three categories of parametrization: elastic, global and local transformation. The elastic transformations respect the partition of unity, there are no holes created or surfaces counted several times. This is commonly used in Image Registration by the use of B-Spline functions and in solid mechanics with finite element basis. The global transformations are defined on the whole picture using rigid body or affine transformation (which is equivalent to homogeneous strain transformation). More complex transformations can be defined such as mechanically based one. These transformations have been used for stress intensity factor identification by and for rod strain by. The local transformation can be considered as the same global transformation defined on several Zone Of Interest (ZOI) of the fixed image. ==== Global ==== Several global transforms have been implemented: Rigid and homogeneous (Tx,Ty,Rz in 2D; Tx,Ty,Tz,Rx,Ry,Rz,Exx,Eyy,Ezz,Eyz,Exz,Exy in 3D) Brazilian (Only in 2D), Dynamic Flexion, ==== Elastic ==== First-order quadrangular finite elements Q4P1 are used in Yadics. ===== Local ===== Every global transform can be used on a local mesh. === Optimization === The YaDICs optimization process follows a gradient descent scheme. The first step is to compute the gradient of the metric regarding the transform parameters ∂ S S D ( μ , I F , I M ) ∂ μ = 2 | Ω F | ∑ x i ∈ Ω F ( I F ( x i ) − I M ( T μ ( x i ) ) ) ∂ I M ( T μ ( x i ) ∂ μ = 2 | Ω F | ∑ x i ∈ Ω F ( I F ( x i ) − I M ( T μ ( x i ) ) ) ( ∂ T μ ( x i ) ∂ μ ) t ∂ I M ( T μ ( x i ) ) ∂ x {\displaystyle {\begin{array}{lcl}{\dfrac {\partial SSD(\mu ,{\mathcal {I_{F}}},{\mathcal {I_{M}}})}{\partial \mu }}&=&{\dfrac {2}{\left|\Omega _{F}\right|}}\sum _{x_{i}\in \Omega _{F}}\left({\mathcal {I_{F}}}(x_{i})-{\mathcal {I_{M}}}({T}_{\mu }(x_{i}))\right){\dfrac {\partial {\mathcal {I_{M}}}({T}_{\mu }(x_{i})}{\partial \mu }}\\&=&{\dfrac {2}{\left|\Omega _{F}\right|}}\sum _{x_{i}\in \Omega _{F}}\left({\mathcal {I_{F}}}(x_{i})-{\mathcal {I_{M}}}({T}_{\mu }(x_{i}))\right)\left({\dfrac {\partial {T}_{\mu }(x_{i})}{\partial \mu }}\right)^{t}{\dfrac {\partial {\mathcal {I_{M}}}({T}_{\mu }(x_{i}))}{\partial x}}\\\end{array}}} ==== Gradient method ==== Once the metric gradient has been computed, one has to find an optimization strategy The gradient method principle is explained below: μ k + 1 = μ k + α k d k {\displaystyle \mu _{k+1}=\mu _{k}+\alpha _{k}d_{k}} The gradient step can be constant or updated at every iteration. d k = − γ k ∂ C ( μ , I F , I M ) ∂ μ {\displaystyle d_{k}=-\gamma _{k}{\dfrac {\partial {\mathcal {C}}(\mu ,{\mathcal {I_{F}}},{\mathcal {I_{M}}})}{\partial \mu }}} , γ k {\displaystyle \gamma _{k}} allows one to choose between the following methods : γ k {\displaystyle \gamma _{k}} ⟹ {\displaystyle \Longrightarrow } steepest descent, γ k = [ ∂ C ( μ , I F , I M ) ∂ μ ∂ C ( μ , I F , I M ) ∂ μ t ] − 1 {\displaystyle \gamma _{k}=\left[{\dfrac {\partial {\mathcal {C}}(\mu ,{\mathcal {I_{F}}},{\mathcal {I_{M}}})}{\partial \mu }}{\dfrac {\partial {\mathcal {C}}(\mu ,{\mathcal {I_{F}}},{\mathcal {I_{M}}})}{\partial \mu }}^{t}\right]^{-1}} ⟹ {\displaystyle \Longrightarrow } Gauss-Newto
Diffusion map
Diffusion maps is a dimensionality reduction or feature extraction algorithm introduced by Coifman and Lafon which computes a family of embeddings of a data set into Euclidean space (often low-dimensional) whose coordinates can be computed from the eigenvectors and eigenvalues of a diffusion operator on the data. The Euclidean distance between points in the embedded space is equal to the "diffusion distance" between probability distributions centered at those points. Different from linear dimensionality reduction methods such as principal component analysis (PCA), diffusion maps are part of the family of nonlinear dimensionality reduction methods which focus on discovering the underlying manifold that the data has been sampled from. By integrating local similarities at different scales, diffusion maps give a global description of the data-set. Compared with other methods, the diffusion map algorithm is robust to noise perturbation and computationally inexpensive. == Definition of diffusion maps == Following and , diffusion maps can be defined in four steps. === Connectivity === Diffusion maps exploit the relationship between heat diffusion and random walk Markov chain. The basic observation is that if we take a random walk on the data, walking to a nearby data-point is more likely than walking to another that is far away. Let ( X , A , μ ) {\displaystyle (X,{\mathcal {A}},\mu )} be a measure space, where X {\displaystyle X} is the data set and μ {\displaystyle \mu } represents the distribution of the points on X {\displaystyle X} . Based on this, the connectivity k {\displaystyle k} between two data points, x {\displaystyle x} and y {\displaystyle y} , can be defined as the probability of walking from x {\displaystyle x} to y {\displaystyle y} in one step of the random walk. Usually, this probability is specified in terms of a kernel function of the two points: k : X × X → R {\displaystyle k:X\times X\rightarrow \mathbb {R} } . For example, the popular Gaussian kernel: k ( x , y ) = exp ( − | | x − y | | 2 ϵ ) {\displaystyle k(x,y)=\exp \left(-{\frac {||x-y||^{2}}{\epsilon }}\right)} More generally, the kernel function has the following properties k ( x , y ) = k ( y , x ) {\displaystyle k(x,y)=k(y,x)} ( k {\displaystyle k} is symmetric) k ( x , y ) ≥ 0 ∀ x , y {\displaystyle k(x,y)\geq 0\,\,\forall x,y} ( k {\displaystyle k} is positivity preserving). The kernel constitutes the prior definition of the local geometry of the data-set. Since a given kernel will capture a specific feature of the data set, its choice should be guided by the application that one has in mind. This is a major difference with methods such as principal component analysis, where correlations between all data points are taken into account at once. Given ( X , k ) {\displaystyle (X,k)} , we can then construct a reversible discrete-time Markov chain on X {\displaystyle X} (a process known as the normalized graph Laplacian construction): d ( x ) = ∫ X k ( x , y ) d μ ( y ) {\displaystyle d(x)=\int _{X}k(x,y)d\mu (y)} and define: p ( x , y ) = k ( x , y ) d ( x ) {\displaystyle p(x,y)={\frac {k(x,y)}{d(x)}}} Although the new normalized kernel does not inherit the symmetric property, it does inherit the positivity-preserving property and gains a conservation property: ∫ X p ( x , y ) d μ ( y ) = 1 {\displaystyle \int _{X}p(x,y)d\mu (y)=1} === Diffusion process === From p ( x , y ) {\displaystyle p(x,y)} we can construct a transition matrix of a Markov chain ( M {\displaystyle M} ) on X {\displaystyle X} . In other words, p ( x , y ) {\displaystyle p(x,y)} represents the one-step transition probability from x {\displaystyle x} to y {\displaystyle y} , and M t {\displaystyle M^{t}} gives the t-step transition matrix. We define the diffusion matrix L {\displaystyle L} (it is also a version of graph Laplacian matrix) L i , j = k ( x i , x j ) {\displaystyle L_{i,j}=k(x_{i},x_{j})\,} We then define the new kernel L i , j ( α ) = k ( α ) ( x i , x j ) = L i , j ( d ( x i ) d ( x j ) ) α {\displaystyle L_{i,j}^{(\alpha )}=k^{(\alpha )}(x_{i},x_{j})={\frac {L_{i,j}}{(d(x_{i})d(x_{j}))^{\alpha }}}\,} or equivalently, L ( α ) = D − α L D − α {\displaystyle L^{(\alpha )}=D^{-\alpha }LD^{-\alpha }\,} where D is a diagonal matrix and D i , i = ∑ j L i , j . {\displaystyle D_{i,i}=\sum _{j}L_{i,j}.} We apply the graph Laplacian normalization to this new kernel: M = ( D ( α ) ) − 1 L ( α ) , {\displaystyle M=({D}^{(\alpha )})^{-1}L^{(\alpha )},\,} where D ( α ) {\displaystyle D^{(\alpha )}} is a diagonal matrix and D i , i ( α ) = ∑ j L i , j ( α ) . {\displaystyle {D}_{i,i}^{(\alpha )}=\sum _{j}L_{i,j}^{(\alpha )}.} p ( x j , t | x i ) = M i , j t {\displaystyle p(x_{j},t|x_{i})=M_{i,j}^{t}\,} One of the main ideas of the diffusion framework is that running the chain forward in time (taking larger and larger powers of M {\displaystyle M} ) reveals the geometric structure of X {\displaystyle X} at larger and larger scales (the diffusion process). Specifically, the notion of a cluster in the data set is quantified as a region in which the probability of escaping this region is low (within a certain time t). Therefore, t not only serves as a time parameter, but it also has the dual role of scale parameter. The eigendecomposition of the matrix M t {\displaystyle M^{t}} yields M i , j t = ∑ l λ l t ψ l ( x i ) ϕ l ( x j ) {\displaystyle M_{i,j}^{t}=\sum _{l}\lambda _{l}^{t}\psi _{l}(x_{i})\phi _{l}(x_{j})\,} where { λ l } {\displaystyle \{\lambda _{l}\}} is the sequence of eigenvalues of M {\displaystyle M} and { ψ l } {\displaystyle \{\psi _{l}\}} and { ϕ l } {\displaystyle \{\phi _{l}\}} are the biorthogonal left and right eigenvectors respectively. Due to the spectrum decay of the eigenvalues, only a few terms are necessary to achieve a given relative accuracy in this sum. ==== Parameter α and the diffusion operator ==== The reason to introduce the normalization step involving α {\displaystyle \alpha } is to tune the influence of the data point density on the infinitesimal transition of the diffusion. In some applications, the sampling of the data is generally not related to the geometry of the manifold we are interested in describing. In this case, we can set α = 1 {\displaystyle \alpha =1} and the diffusion operator approximates the Laplace–Beltrami operator. We then recover the Riemannian geometry of the data set regardless of the distribution of the points. To describe the long-term behavior of the point distribution of a system of stochastic differential equations, we can use α = 0.5 {\displaystyle \alpha =0.5} and the resulting Markov chain approximates the Fokker–Planck diffusion. With α = 0 {\displaystyle \alpha =0} , it reduces to the classical graph Laplacian normalization. === Diffusion distance === The diffusion distance at time t {\displaystyle t} between two points can be measured as the similarity of two points in the observation space with the connectivity between them. It is given by D t ( x i , x j ) 2 = ∑ y ( p ( y , t | x i ) − p ( y , t | x j ) ) 2 ϕ 0 ( y ) {\displaystyle D_{t}(x_{i},x_{j})^{2}=\sum _{y}{\frac {(p(y,t|x_{i})-p(y,t|x_{j}))^{2}}{\phi _{0}(y)}}} where ϕ 0 ( y ) {\displaystyle \phi _{0}(y)} is the stationary distribution of the Markov chain, given by the first left eigenvector of M {\displaystyle M} . Explicitly: ϕ 0 ( y ) = d ( y ) ∑ z ∈ X d ( z ) {\displaystyle \phi _{0}(y)={\frac {d(y)}{\sum _{z\in X}d(z)}}} Intuitively, D t ( x i , x j ) {\displaystyle D_{t}(x_{i},x_{j})} is small if there is a large number of short paths connecting x i {\displaystyle x_{i}} and x j {\displaystyle x_{j}} . There are several interesting features associated with the diffusion distance, based on our previous discussion that t {\displaystyle t} also serves as a scale parameter: Points are closer at a given scale (as specified by D t ( x i , x j ) {\displaystyle D_{t}(x_{i},x_{j})} ) if they are highly connected in the graph, therefore emphasizing the concept of a cluster. This distance is robust to noise, since the distance between two points depends on all possible paths of length t {\displaystyle t} between the points. From a machine learning point of view, the distance takes into account all evidences linking x i {\displaystyle x_{i}} to x j {\displaystyle x_{j}} , allowing us to conclude that this distance is appropriate for the design of inference algorithms based on the majority of preponderance. === Diffusion process and low-dimensional embedding === The diffusion distance can be calculated using the eigenvectors by D t ( x i , x j ) 2 = ∑ l λ l 2 t ( ψ l ( x i ) − ψ l ( x j ) ) 2 {\displaystyle D_{t}(x_{i},x_{j})^{2}=\sum _{l}\lambda _{l}^{2t}(\psi _{l}(x_{i})-\psi _{l}(x_{j}))^{2}\,} So the eigenvectors can be used as a new set of coordinates for the data. The diffusion map is defined as: Ψ t ( x ) = ( λ 1 t ψ 1 ( x ) , λ 2 t ψ 2 ( x ) , … , λ k t ψ k ( x ) ) {\displaystyle \Psi _{t}(x)=(\lambda _{1}^{t}\psi _{1}(x),\lambda _{2}^{t}\psi _{2}(x),\ld
Radial basis function network
In the field of mathematical modeling, a radial basis function network is an artificial neural network that uses radial basis functions as activation functions. The output of the network is a linear combination of radial basis functions of the inputs and neuron parameters. Radial basis function networks have many uses, including function approximation, time series prediction, classification, and system control. They were first formulated in a 1988 paper by Broomhead and Lowe, both researchers at the Royal Signals and Radar Establishment. == Network architecture == Radial basis function (RBF) networks typically have three layers: an input layer, a hidden layer with a non-linear RBF activation function and a linear output layer. The input can be modeled as a vector of real numbers x ∈ R n {\displaystyle \mathbf {x} \in \mathbb {R} ^{n}} . The output of the network is then a scalar function of the input vector, φ : R n → R {\displaystyle \varphi :\mathbb {R} ^{n}\to \mathbb {R} } , and is given by φ ( x ) = ∑ i = 1 N a i ρ ( | | x − c i | | ) {\displaystyle \varphi (\mathbf {x} )=\sum _{i=1}^{N}a_{i}\rho (||\mathbf {x} -\mathbf {c} _{i}||)} where N {\displaystyle N} is the number of neurons in the hidden layer, c i {\displaystyle \mathbf {c} _{i}} is the center vector for neuron i {\displaystyle i} , and a i {\displaystyle a_{i}} is the weight of neuron i {\displaystyle i} in the linear output neuron. Functions that depend only on the distance from a center vector are radially symmetric about that vector, hence the name radial basis function. In the basic form, all inputs are connected to each hidden neuron. The norm is typically taken to be the Euclidean distance (although the Mahalanobis distance appears to perform better with pattern recognition) and the radial basis function is commonly taken to be Gaussian ρ ( ‖ x − c i ‖ ) = exp [ − β i ‖ x − c i ‖ 2 ] {\displaystyle \rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}=\exp \left[-\beta _{i}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert ^{2}\right]} . The Gaussian basis functions are local to the center vector in the sense that lim | | x | | → ∞ ρ ( ‖ x − c i ‖ ) = 0 {\displaystyle \lim _{||x||\to \infty }\rho (\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert )=0} i.e. changing parameters of one neuron has only a small effect for input values that are far away from the center of that neuron. Given certain mild conditions on the shape of the activation function, RBF networks are universal approximators on a compact subset of R n {\displaystyle \mathbb {R} ^{n}} . This means that an RBF network with enough hidden neurons can approximate any continuous function on a closed, bounded set with arbitrary precision. The parameters a i {\displaystyle a_{i}} , c i {\displaystyle \mathbf {c} _{i}} , and β i {\displaystyle \beta _{i}} are determined in a manner that optimizes the fit between φ {\displaystyle \varphi } and the data. === Normalization === ==== Normalized architecture ==== In addition to the above unnormalized architecture, RBF networks can be normalized. In this case the mapping is φ ( x ) = d e f ∑ i = 1 N a i ρ ( ‖ x − c i ‖ ) ∑ i = 1 N ρ ( ‖ x − c i ‖ ) = ∑ i = 1 N a i u ( ‖ x − c i ‖ ) {\displaystyle \varphi (\mathbf {x} )\ {\stackrel {\mathrm {def} }{=}}\ {\frac {\sum _{i=1}^{N}a_{i}\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}}{\sum _{i=1}^{N}\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}}}=\sum _{i=1}^{N}a_{i}u{\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}} where u ( ‖ x − c i ‖ ) = d e f ρ ( ‖ x − c i ‖ ) ∑ j = 1 N ρ ( ‖ x − c j ‖ ) {\displaystyle u{\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}\ {\stackrel {\mathrm {def} }{=}}\ {\frac {\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}}{\sum _{j=1}^{N}\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{j}\right\Vert {\big )}}}} is known as a normalized radial basis function. ==== Theoretical motivation for normalization ==== There is theoretical justification for this architecture in the case of stochastic data flow. Assume a stochastic kernel approximation for the joint probability density P ( x ∧ y ) = 1 N ∑ i = 1 N ρ ( ‖ x − c i ‖ ) σ ( | y − e i | ) {\displaystyle P\left(\mathbf {x} \land y\right)={1 \over N}\sum _{i=1}^{N}\,\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}\,\sigma {\big (}\left\vert y-e_{i}\right\vert {\big )}} where the weights c i {\displaystyle \mathbf {c} _{i}} and e i {\displaystyle e_{i}} are exemplars from the data and we require the kernels to be normalized ∫ ρ ( ‖ x − c i ‖ ) d n x = 1 {\displaystyle \int \rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}\,d^{n}\mathbf {x} =1} and ∫ σ ( | y − e i | ) d y = 1 {\displaystyle \int \sigma {\big (}\left\vert y-e_{i}\right\vert {\big )}\,dy=1} . The probability densities in the input and output spaces are P ( x ) = ∫ P ( x ∧ y ) d y = 1 N ∑ i = 1 N ρ ( ‖ x − c i ‖ ) {\displaystyle P\left(\mathbf {x} \right)=\int P\left(\mathbf {x} \land y\right)\,dy={1 \over N}\sum _{i=1}^{N}\,\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}} and The expectation of y given an input x {\displaystyle \mathbf {x} } is φ ( x ) = d e f E ( y ∣ x ) = ∫ y P ( y ∣ x ) d y {\displaystyle \varphi \left(\mathbf {x} \right)\ {\stackrel {\mathrm {def} }{=}}\ E\left(y\mid \mathbf {x} \right)=\int y\,P\left(y\mid \mathbf {x} \right)dy} where P ( y ∣ x ) {\displaystyle P\left(y\mid \mathbf {x} \right)} is the conditional probability of y given x {\displaystyle \mathbf {x} } . The conditional probability is related to the joint probability through Bayes' theorem P ( y ∣ x ) = P ( x ∧ y ) P ( x ) {\displaystyle P\left(y\mid \mathbf {x} \right)={\frac {P\left(\mathbf {x} \land y\right)}{P\left(\mathbf {x} \right)}}} which yields φ ( x ) = ∫ y P ( x ∧ y ) P ( x ) d y {\displaystyle \varphi \left(\mathbf {x} \right)=\int y\,{\frac {P\left(\mathbf {x} \land y\right)}{P\left(\mathbf {x} \right)}}\,dy} . This becomes φ ( x ) = ∑ i = 1 N e i ρ ( ‖ x − c i ‖ ) ∑ i = 1 N ρ ( ‖ x − c i ‖ ) = ∑ i = 1 N e i u ( ‖ x − c i ‖ ) {\displaystyle \varphi \left(\mathbf {x} \right)={\frac {\sum _{i=1}^{N}e_{i}\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}}{\sum _{i=1}^{N}\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}}}=\sum _{i=1}^{N}e_{i}u{\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}} when the integrations are performed. === Local linear models === It is sometimes convenient to expand the architecture to include local linear models. In that case the architectures become, to first order, φ ( x ) = ∑ i = 1 N ( a i + b i ⋅ ( x − c i ) ) ρ ( ‖ x − c i ‖ ) {\displaystyle \varphi \left(\mathbf {x} \right)=\sum _{i=1}^{N}\left(a_{i}+\mathbf {b} _{i}\cdot \left(\mathbf {x} -\mathbf {c} _{i}\right)\right)\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}} and φ ( x ) = ∑ i = 1 N ( a i + b i ⋅ ( x − c i ) ) u ( ‖ x − c i ‖ ) {\displaystyle \varphi \left(\mathbf {x} \right)=\sum _{i=1}^{N}\left(a_{i}+\mathbf {b} _{i}\cdot \left(\mathbf {x} -\mathbf {c} _{i}\right)\right)u{\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )}} in the unnormalized and normalized cases, respectively. Here b i {\displaystyle \mathbf {b} _{i}} are weights to be determined. Higher order linear terms are also possible. This result can be written φ ( x ) = ∑ i = 1 2 N ∑ j = 1 n e i j v i j ( x − c i ) {\displaystyle \varphi \left(\mathbf {x} \right)=\sum _{i=1}^{2N}\sum _{j=1}^{n}e_{ij}v_{ij}{\big (}\mathbf {x} -\mathbf {c} _{i}{\big )}} where e i j = { a i , if i ∈ [ 1 , N ] b i j , if i ∈ [ N + 1 , 2 N ] {\displaystyle e_{ij}={\begin{cases}a_{i},&{\mbox{if }}i\in [1,N]\\b_{ij},&{\mbox{if }}i\in [N+1,2N]\end{cases}}} and v i j ( x − c i ) = d e f { δ i j ρ ( ‖ x − c i ‖ ) , if i ∈ [ 1 , N ] ( x i j − c i j ) ρ ( ‖ x − c i ‖ ) , if i ∈ [ N + 1 , 2 N ] {\displaystyle v_{ij}{\big (}\mathbf {x} -\mathbf {c} _{i}{\big )}\ {\stackrel {\mathrm {def} }{=}}\ {\begin{cases}\delta _{ij}\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )},&{\mbox{if }}i\in [1,N]\\\left(x_{ij}-c_{ij}\right)\rho {\big (}\left\Vert \mathbf {x} -\mathbf {c} _{i}\right\Vert {\big )},&{\mbox{if }}i\in [N+1,2N]\end{cases}}} in the unnormalized case and in the normalized case. Here δ i j {\displaystyle \delta _{ij}} is a Kronecker delta function defined as δ i j = { 1 , if i = j 0 , if i ≠ j {\displaystyle \delta _{ij}={\begin{cases}1,&{\mbox{if }}i=j\\0,&{\mbox{if }}i\neq j\end{cases}}} . == Training == RBF networks are typically trained from pairs of input and target values x ( t ) , y ( t ) {\displaystyle \mathbf {x} (t),y(t)} , t = 1 , … , T {\displaystyle t=1,\dots ,T} by a two-step algorithm. In the first step, the center vectors c i {\displaystyle \mathbf {c} _{i}} of the RBF functions in the hidden layer
Ho–Kashyap algorithm
The Ho–Kashyap algorithm is an iterative method in machine learning for finding a linear decision boundary that separates two linearly separable classes. It was developed by Yu-Chi Ho and Rangasami L. Kashyap in 1965, and usually presented as a problem in linear programming. == Setup == Given a training set consisting of samples from two classes, the Ho–Kashyap algorithm seeks to find a weight vector w {\displaystyle \mathbf {w} } and a margin vector b {\displaystyle \mathbf {b} } such that: Y w = b {\displaystyle \mathbf {Yw} =\mathbf {b} } where Y {\displaystyle \mathbf {Y} } is the augmented data matrix with samples from both classes (with appropriate sign conventions, e.g., samples from class 2 are negated), w {\displaystyle \mathbf {w} } is the weight vector to be determined, and b {\displaystyle \mathbf {b} } is a positive margin vector. The algorithm minimizes the criterion function: J ( w , b ) = | | Y w − b | | 2 {\displaystyle J(\mathbf {w} ,\mathbf {b} )=||\mathbf {Yw} -\mathbf {b} ||^{2}} subject to the constraint that b > 0 {\displaystyle \mathbf {b} >\mathbf {0} } (element-wise). Given a problem of linearly separating two classes, we consider a dataset of elements { ( x i , y i ) } i ∈ 1 : N {\displaystyle \{(\mathbf {x_{i}} ,y_{i})\}_{i\in 1:N}} where y i ∈ { − 1 , + 1 } {\displaystyle y_{i}\in \{-1,+1\}} . Linearly separating them by a perceptron is equivalent to finding weight and bias w , b {\displaystyle \mathbf {w} ,b} for a perceptron, such that: [ y 1 x 1 1 ⋮ ⋮ y N x N 1 ] [ w b ] > 0 {\displaystyle {\begin{bmatrix}y_{1}\mathbf {x} _{1}&1\\\vdots &\vdots \\y_{N}\mathbf {x} _{N}&1\\\end{bmatrix}}{\begin{bmatrix}\mathbf {w} \\b\end{bmatrix}}>0} == Algorithm == The idea of the Ho–Kashyap algorithm is as follows: Given any b {\displaystyle \mathbf {b} } , the corresponding w {\displaystyle \mathbf {w} } is known: It is simply w = Y + b {\displaystyle \mathbf {w} =\mathbf {Y} ^{+}\mathbf {b} } , where Y + {\displaystyle \mathbf {Y} ^{+}} denotes the Moore–Penrose pseudoinverse of Y {\displaystyle \mathbf {Y} } . Therefore, it only remains to find b {\displaystyle \mathbf {b} } by gradient descent. However, the gradient descent may sometimes decrease some of the coordinates of b {\displaystyle \mathbf {b} } , which may cause some coordinates of b {\displaystyle \mathbf {b} } to become negative, which is undesirable. Therefore, whenever some coordinates of b {\displaystyle \mathbf {b} } would have decreased, those coordinates are unchanged instead. As for the coordinates of b {\displaystyle \mathbf {b} } that would increase, those would increase without issue. Formally, the algorithm is as follows: Initialization: Set b ( 0 ) {\displaystyle \mathbf {b} (0)} to an arbitrary positive vector, typically b ( 0 ) = 1 {\displaystyle \mathbf {b} (0)=\mathbf {1} } (a vector of ones). Set the iteration counter k = 0 {\displaystyle k=0} . Set w ( 0 ) = Y + b ( 0 ) {\displaystyle \mathbf {w} (0)=\mathbf {Y} ^{+}\mathbf {b} (0)} Loop until convergence, or until iteration counter exceeds some k m a x {\displaystyle k_{max}} . Error calculation: Compute the error vector: e ( k ) = Y w ( k ) − b ( k ) {\displaystyle \mathbf {e} (k)=\mathbf {Yw} (k)-\mathbf {b} (k)} . Margin update: Update the margin vector: b ( k + 1 ) = b ( k ) + 2 η k ( e ( k ) + | e ( k ) | ) {\displaystyle \mathbf {b} (k+1)=\mathbf {b} (k)+2\eta _{k}(\mathbf {e} (k)+|\mathbf {e} (k)|)} where η k {\displaystyle \eta _{k}} is a positive learning rate parameter, and | e ( k ) | {\displaystyle |\mathbf {e} (k)|} denotes the element-wise absolute value. Weight calculation: Compute the weight vector using the pseudoinverse: w ( k + 1 ) = Y + b ( k + 1 ) {\displaystyle \mathbf {w} (k+1)=\mathbf {Y} ^{+}\mathbf {b} (k+1)} . Convergence check: If | | e ( k ) | | ≤ θ {\displaystyle ||\mathbf {e} (k)||\leq \theta } for some predetermined threshold θ {\displaystyle \theta } (close to zero), then return b ( k + 1 ) , w ( k + 1 ) {\displaystyle \mathbf {b} (k+1),\mathbf {w} (k+1)} . if e ( k ) ≤ 0 {\displaystyle \mathbf {e} (k)\leq \mathbf {0} } (all components non-positive), return "Samples not separable.". Return "Algorithm failed to converge in time.". == Properties == If the training data is linearly separable, the algorithm converges to a solution (where e ( k ) = 0 {\displaystyle \mathbf {e} (k)=\mathbf {0} } ) in a finite number of iterations. If the data is not linearly separable, the algorithm may or may not ever reach the point where e ( k ) = 0 {\displaystyle \mathbf {e} (k)=\mathbf {0} } . However, if it does happen that e ( k ) ≤ 0 {\displaystyle \mathbf {e} (k)\leq \mathbf {0} } at some iteration, this proves non-separability. The convergence rate depends on the choice of the learning rate parameter ρ {\displaystyle \rho } and the degree of linear separability of the data. == Relationship to other algorithms == Perceptron algorithm: Both seek linear separators. The perceptron updates weights incrementally based on individual misclassified samples, while Ho–Kashyap is a batch method that processes all samples to compute the pseudoinverse and updates based on an overall error vector. Linear discriminant analysis (LDA): LDA assumes underlying Gaussian distributions with equal covariances for the classes and derives the decision boundary from these statistical assumptions. Ho–Kashyap makes no explicit distributional assumptions and instead tries to solve a system of linear inequalities directly. Support vector machines (SVM): For linearly separable data, SVMs aim to find the maximum-margin hyperplane. The Ho–Kashyap algorithm finds a separating hyperplane but not necessarily the one with the maximum margin. If the data is not separable, soft-margin SVMs allow for some misclassifications by optimizing a trade-off between margin size and misclassification penalty, while Ho–Kashyap provides a least-squares solution. == Variants == Modified Ho–Kashyap algorithm changes weight calculation step w ( k + 1 ) = Y + b ( k + 1 ) {\displaystyle \mathbf {w} (k+1)=\mathbf {Y} ^{+}\mathbf {b} (k+1)} to w ( k + 1 ) = w ( k ) + η k Y + | e ( k ) | {\displaystyle \mathbf {w} (k+1)=\mathbf {w} (k)+\eta _{k}\mathbf {Y} ^{+}|\mathbf {e} (k)|} . Kernel Ho–Kashyap algorithm: Applies kernel methods (the "kernel trick") to the Ho–Kashyap framework to enable non-linear classification by implicitly mapping data to a higher-dimensional feature space.
Color histogram
In image processing and photography, a color histogram is a representation of the distribution of colors in an image. For digital images, a color histogram represents the number of pixels that have colors in each of a fixed list of color ranges that span the image's color space (the set of all possible colors). A color histogram can be built for any kind of color space, although the term is more often used for three-dimensional spaces such as RGB or HSV. For monochromatic images, the term intensity histogram may be used instead. For multi-spectral images, where each pixel is represented by an arbitrary number of measurements (for example, beyond the three measurements in RGB), a color histogram is N-dimensional, with N being the number of measurements taken. Each measurement has its own wavelength range of the light spectrum, some of which may be outside the visible spectrum. If the set of possible color values is sufficiently small, each of those colors may be placed on a range by itself; then the histogram is merely the count of pixels that have each possible color. Most often, the space is divided into an appropriate number of ranges, often arranged as a regular grid, each containing many similar color values. A color histogram may also be represented and displayed as a smooth function defined over the color space that approximates the pixel counts. Like other kinds of histograms, a color histogram is a statistic that can be viewed as an approximation of an underlying continuous distribution of color values. == Overview == Color histograms are flexible constructs that can be built from images in various color spaces, whether RGB, rg chromaticity or any other color space of any dimension. A histogram of an image is produced first by discretization of the colors in the image into a number of bins, and counting the number of image pixels in each bin. For example, a red–blue chromaticity histogram can be formed by first normalizing color pixel values by dividing RGB values by R+G+B, then quantizing the normalized R and B coordinates into N bins each. A two-dimensional histogram of red–blue chromaticity divided into four bins (N=4) may yield a histogram similar to this table: A histogram can be N-dimensional. Although harder to display, a three-dimensional color histogram for the above example could be thought of as four separate red–blue histograms, where each of the four histograms contains the red–blue values for a bin of green (0–63, 64–127, 128–191, and 192–255). The histogram provides a compact summarization of the distribution of data in an image. A color histogram of an image is relatively invariant with translation and rotation about the viewing axis, and varies only slowly with the angle of view. By comparing histogram signatures of two images and matching the color content of one image with the other, a color histogram is particularly well suited for the problem of recognizing an object of unknown position and rotation within a scene. Importantly, translation of an RGB image into the illumination invariant rg-chromaticity space allows the histogram to operate well in varying light levels. 1. What is a histogram? A histogram is a graphical representation of the number of pixels in an image. In a more simple way to explain, a histogram is a bar graph, whose X-axis represents the tonal scale (black at the left and white at the right), and Y-axis represents the number of pixels in an image in a certain area of the tonal scale. For example, the graph of a luminance histogram shows the number of pixels for each brightness level (from black to white), and when there are more pixels, the peak at the certain luminance level is higher. 2. What is a color histogram? A color histogram of an image represents the distribution of the composition of colors in the image. It shows different types of colors appeared and the number of pixels in each type of the colors appeared. The relation between a color histogram and a luminance histogram is that a color histogram can be also expressed as “three luminance histograms”, each of which shows the brightness distribution of each individual red/green/blue color channel. == Characteristics of a color histogram == A color histogram focuses only on the proportion of the number of different types of colors, regardless of the spatial location of the colors. The values of a color histogram are from statistics. They show the statistical distribution of colors and the essential tone of an image. In general, as the color distributions of the foreground and background in an image are different, there might be a bimodal distribution in the histogram. For the luminance histogram alone, there is no perfect histogram and in general, the histogram can tell whether it is over-exposure or not, but there are times when you might think the image is over exposed by viewing the histogram; however, in reality it is not. == Principles of the formation of a color histogram == The formation of a color histogram is rather simple. From the definition above, we can simply count the number of pixels for each 256 scales in each of the 3 RGB channel, and plot them on 3 individual bar graphs. In general, a color histogram is based on a certain color space, such as RGB or HSV. When we compute the pixels of different colors in an image, if the color space is large, then we can first divide the color space into certain numbers of small intervals. Each of the intervals is called a bin. This process is called color quantization. Then, by counting the number of pixels in each of the bins, we get a color histogram of the image. The concrete steps of the principles can be viewed in Example 1. == Examples == === Example 1 === Given the following image of a cat (an original version and a version that has been reduced to 256 colors for easy histogram purposes), the following data represents a color histogram in the RGB color space, using four bins. Bin 0 corresponds to intensities 0–63 Bin 1 is 64–127 Bin 2 is 128–191 and Bin 3 is 192–255. === Example 2 === Application in camera: Nowadays, some cameras have the ability to show the 3 color histograms when we take photos. We can examine clips (spikes on either the black or white side of the scale) in each of the 3 RGB color histograms. If we find one or more clipping on a channel of the 3 RGB channels, then this would result in a loss of detail for that color. To illustrate this, consider this example: We know that each of the three R, G, B channels has a range of values from 0 to 255 (8 bit). So consider a photo that has a luminance range of 0–255. Assume the photo we take is made of 4 blocks that are adjacent to each other and we set the luminance scale for each of the 4 blocks of original photo to be 10, 100, 205, 245. Thus, the image looks like the topmost figure on the right. Then, we overexpose the photo a little, say, the luminance scale of each block is increased by 10. Thus, the luminance scale for each of the 4 blocks of new photo is 20, 110, 215, 255. Then, the image looks like the second figure on the right. There is not much difference between both figures, all we can see is that the whole image becomes brighter (the contrast for each of the blocks remain the same). Now, we overexpose the original photo again, this time the luminance scale of each block is increased by 50. Thus, the luminance scale for each of the 4 blocks of the new photo is 60, 150, 255, 255. The new image now looks like the third figure on the right. Note that the scale for the last block is 255 instead of 295, for 255 is the top scale and thus the last block has clipped. When this happens, we lose the contrast of the last 2 blocks, and thus we cannot recover the image no matter how we adjust it. To conclude, when taking photos with a camera that displays histograms, always keep the brightest tone in the image below the largest scale 255 on the histogram in order to avoid losing details. == Drawbacks and other approaches == The main drawback of histograms for classification is that the representation is dependent on the color of the object being studied, ignoring its shape and texture. Color histograms can potentially be identical for two images with different object content which happens to share color information. Conversely, without spatial or shape information, similar objects of different color may be indistinguishable based solely on color histogram comparisons. There is no way to distinguish a red and white cup from a red and white plate. Put it another way: histogram-based algorithms have no concept of a generic 'cup', and a model of a red and white cup is no use when given an otherwise identical blue and white cup. Another problem is that color histograms have high sensitivity to noisy interference such as lighting intensity changes and quantization errors. High dimensionality (bins) color histograms are also another issue. Some color histogram feature spaces often occupy more than one hundred di
Semidefinite embedding
Maximum Variance Unfolding (MVU), also known as Semidefinite Embedding (SDE), is an algorithm in computer science that uses semidefinite programming to perform non-linear dimensionality reduction of high-dimensional vectorial input data. It is motivated by the observation that kernel Principal Component Analysis (kPCA) does not reduce the data dimensionality, as it leverages the Kernel trick to non-linearly map the original data into an inner-product space. == Algorithm == MVU creates a mapping from the high dimensional input vectors to some low dimensional Euclidean vector space in the following steps: A neighbourhood graph is created. Each input is connected with its k-nearest input vectors (according to Euclidean distance metric) and all k-nearest neighbors are connected with each other. If the data is sampled well enough, the resulting graph is a discrete approximation of the underlying manifold. The neighbourhood graph is "unfolded" with the help of semidefinite programming. Instead of learning the output vectors directly, the semidefinite programming aims to find an inner product matrix that maximizes the pairwise distances between any two inputs that are not connected in the neighbourhood graph while preserving the nearest neighbors distances. The low-dimensional embedding is finally obtained by application of multidimensional scaling on the learned inner product matrix. The steps of applying semidefinite programming followed by a linear dimensionality reduction step to recover a low-dimensional embedding into a Euclidean space were first proposed by Linial, London, and Rabinovich. == Optimization formulation == Let X {\displaystyle X\,\!} be the original input and Y {\displaystyle Y\,\!} be the embedding. If i , j {\displaystyle i,j\,\!} are two neighbors, then the local isometry constraint that needs to be satisfied is: | X i − X j | 2 = | Y i − Y j | 2 {\displaystyle |X_{i}-X_{j}|^{2}=|Y_{i}-Y_{j}|^{2}\,\!} Let G , K {\displaystyle G,K\,\!} be the Gram matrices of X {\displaystyle X\,\!} and Y {\displaystyle Y\,\!} (i.e.: G i j = X i ⋅ X j , K i j = Y i ⋅ Y j {\displaystyle G_{ij}=X_{i}\cdot X_{j},K_{ij}=Y_{i}\cdot Y_{j}\,\!} ). We can express the above constraint for every neighbor points i , j {\displaystyle i,j\,\!} in term of G , K {\displaystyle G,K\,\!} : G i i + G j j − G i j − G j i = K i i + K j j − K i j − K j i {\displaystyle G_{ii}+G_{jj}-G_{ij}-G_{ji}=K_{ii}+K_{jj}-K_{ij}-K_{ji}\,\!} In addition, we also want to constrain the embedding Y {\displaystyle Y\,\!} to center at the origin: 0 = | ∑ i Y i | 2 ⇔ ( ∑ i Y i ) ⋅ ( ∑ i Y i ) ⇔ ∑ i , j Y i ⋅ Y j ⇔ ∑ i , j K i j {\displaystyle 0=|\sum _{i}Y_{i}|^{2}\Leftrightarrow (\sum _{i}Y_{i})\cdot (\sum _{i}Y_{i})\Leftrightarrow \sum _{i,j}Y_{i}\cdot Y_{j}\Leftrightarrow \sum _{i,j}K_{ij}} As described above, except the distances of neighbor points are preserved, the algorithm aims to maximize the pairwise distance of every pair of points. The objective function to be maximized is: T ( Y ) = 1 2 N ∑ i , j | Y i − Y j | 2 {\displaystyle T(Y)={\dfrac {1}{2N}}\sum _{i,j}|Y_{i}-Y_{j}|^{2}} Intuitively, maximizing the function above is equivalent to pulling the points as far away from each other as possible and therefore "unfold" the manifold. The local isometry constraint Let τ = m a x { η i j | Y i − Y j | 2 } {\displaystyle \tau =max\{\eta _{ij}|Y_{i}-Y_{j}|^{2}\}\,\!} where η i j := { 1 if i is a neighbour of j 0 otherwise . {\displaystyle \eta _{ij}:={\begin{cases}1&{\mbox{if}}\ i{\mbox{ is a neighbour of }}j\\0&{\mbox{otherwise}}.\end{cases}}} prevents the objective function from diverging (going to infinity). Since the graph has N points, the distance between any two points | Y i − Y j | 2 ≤ N τ {\displaystyle |Y_{i}-Y_{j}|^{2}\leq N\tau \,\!} . We can then bound the objective function as follows: T ( Y ) = 1 2 N ∑ i , j | Y i − Y j | 2 ≤ 1 2 N ∑ i , j ( N τ ) 2 = N 3 τ 2 2 {\displaystyle T(Y)={\dfrac {1}{2N}}\sum _{i,j}|Y_{i}-Y_{j}|^{2}\leq {\dfrac {1}{2N}}\sum _{i,j}(N\tau )^{2}={\dfrac {N^{3}\tau ^{2}}{2}}\,\!} The objective function can be rewritten purely in the form of the Gram matrix: T ( Y ) = 1 2 N ∑ i , j | Y i − Y j | 2 = 1 2 N ∑ i , j ( Y i 2 + Y j 2 − Y i ⋅ Y j − Y j ⋅ Y i ) = 1 2 N ( ∑ i , j Y i 2 + ∑ i , j Y j 2 − ∑ i , j Y i ⋅ Y j − ∑ i , j Y j ⋅ Y i ) = 1 2 N ( ∑ i , j Y i 2 + ∑ i , j Y j 2 − 0 − 0 ) = 1 N ( ∑ i Y i 2 ) = 1 N ( T r ( K ) ) {\displaystyle {\begin{aligned}T(Y)&{}={\dfrac {1}{2N}}\sum _{i,j}|Y_{i}-Y_{j}|^{2}\\&{}={\dfrac {1}{2N}}\sum _{i,j}(Y_{i}^{2}+Y_{j}^{2}-Y_{i}\cdot Y_{j}-Y_{j}\cdot Y_{i})\\&{}={\dfrac {1}{2N}}(\sum _{i,j}Y_{i}^{2}+\sum _{i,j}Y_{j}^{2}-\sum _{i,j}Y_{i}\cdot Y_{j}-\sum _{i,j}Y_{j}\cdot Y_{i})\\&{}={\dfrac {1}{2N}}(\sum _{i,j}Y_{i}^{2}+\sum _{i,j}Y_{j}^{2}-0-0)\\&{}={\dfrac {1}{N}}(\sum _{i}Y_{i}^{2})={\dfrac {1}{N}}(Tr(K))\\\end{aligned}}\,\!} Finally, the optimization can be formulated as: Maximize T r ( K ) subject to K ⪰ 0 , ∑ i j K i j = 0 and G i i + G j j − G i j − G j i = K i i + K j j − K i j − K j i , ∀ i , j where η i j = 1 , {\displaystyle {\begin{aligned}&{\text{Maximize}}&&Tr(\mathbf {K} )\\&{\text{subject to}}&&\mathbf {K} \succeq 0,\sum _{ij}\mathbf {K} _{ij}=0\\&{\text{and}}&&G_{ii}+G_{jj}-G_{ij}-G_{ji}=K_{ii}+K_{jj}-K_{ij}-K_{ji},\forall i,j{\mbox{ where }}\eta _{ij}=1,\end{aligned}}} After the Gram matrix K {\displaystyle K\,\!} is learned by semidefinite programming, the output Y {\displaystyle Y\,\!} can be obtained via Cholesky decomposition. In particular, the Gram matrix can be written as K i j = ∑ α = 1 N ( λ α V α i V α j ) {\displaystyle K_{ij}=\sum _{\alpha =1}^{N}(\lambda _{\alpha }V_{\alpha i}V_{\alpha j})\,\!} where V α i {\displaystyle V_{\alpha i}\,\!} is the i-th element of eigenvector V α {\displaystyle V_{\alpha }\,\!} of the eigenvalue λ α {\displaystyle \lambda _{\alpha }\,\!} . It follows that the α {\displaystyle \alpha \,\!} -th element of the output Y i {\displaystyle Y_{i}\,\!} is λ α V α i {\displaystyle {\sqrt {\lambda _{\alpha }}}V_{\alpha i}\,\!} .
